AL8-C

Featuring the cutting edge ZYC SIMPO 5000 LiFePO4 battery modules and the DEYE 10 KW on-grid, CEC approved Hybrid battery inverter.

Pre-wired, pre-tested and pre-commissioned, these cabinets are ready to be placed on-site and significantly reduce site installation time and effort. connect up the solar panels, generator and the AC cabling and that’s it.

SKU: AL8-C Category:

Enquire Now To Find Out More About This Product

Description

  • Wescor tried and tested, powder coasted aluminum battery cabinet
  • Single phase or Three phase CEC approved 10KW DEYE hybrid inverter with inputs from gird, back-up generator and solar. This inverter will continue supplying power to the house when the grid fails and will start and run electric motos such as water pumps where a lot of other hybrid inverters will not.
  • DEYE 10KW Single phase
  • DEYE 10KWThree phase
  • CEC approved batteries from ZYC with 5.12KWh of storage per module ranging from 2 modules (10.24KWh) up to 8 modules (40.96KWh)
  • ZYC SIMPO5000 LifePO4 http://Datasheet of SIMPO 5000_EN
  • Pre-wired, pre-tested and pre-commissioned, these cabinets are ready to be placed on-site and significantly reduce site installation time and effort. Connect up the solar panels, generator and the AC cabling and that’s it





Additional information

Phase Type

Single Phase, Three Phase
Battery modules

2, 4, 6, 8
External height with cover

1,438 mm (56.61 in)
External cabinet width

1,400 mm (55.12 in)
External width a base of flange

1,500 mm (59.06 in)
External depth

585 mm (23.03 in)
Internal usable depth

550 mm (21.65 in)
Mounting Plate height

1,120 mm (44.09 in)
Mounting Plate width

720 mm (28.35 in)
Mounting Plinth depth

585 mm (23.03 in)
Mounting Plinth width

1,500 mm (59.06 in)
Material

Aluminum
Thickness

3 mm (0.12 in)
Finish

Powder Coating
